無塵等級:Class 100;

Parameters: dust free grade: Class 100;

含氧量:<=20ppm (動態(tài)監(jiān)控);

Oxygen content: < = 20ppm (dynamic monitoring);

溫度范圍: +60~ +500°C；

 Temperature range: + 60 ～ + 500 ° C;

溫度均勻度:±1.5% (空載) ;

Temperature uniformity: ± 1.5% (no load);

升溫速度:常溫~+400°C，升溫速率 > 6°C/min;

Heating rate: room temperature ~ + 400 ° C, heating rate > 6 ° C / min;

降溫速度：夾層降溫裝置，平均速率 5℃/min以內(nèi);

Cooling rate: sandwich cooling device, the average rate is less than 5 ℃ / min；

降溫斜率可設(shè)定，1.5h可從375℃ 降溫到80℃;

The cooling slope can be set, and the temperature can be reduced from 375 ℃ to 80 ℃ in 1.5 h;

溫度過沖：<2℃@200℃，<3℃@300℃；

Temperature overshoot: < 2 ℃ @ 200 ℃, < 3 ℃ @ 300 ℃;

溫控精度:±1°C (空載);

Temperature control accuracy: ± 1 ° C (no load);

工作腔尺寸: W966 mm×H715 mm×D588 mm;

Working chamber size: w966 mm × H715 mm × D588 mm;

Single chamber;

外形尺寸:W1910 mm×H1930 mm×D1037 mm;

Overall dimension: w1910 mm × H1930 mm × D1037 mm;

烘箱擱板為活動式，共兩片, 擱板承重≥30kg;

The drying oven shelf is movable, with two pieces in total, and the shelf load is more than or equal to 30kg;

加熱功率:18KW;

Heating power: 18kw;
